Description
Overview
Essential details
- Condition:
-
New
- Applicable Industries:
-
Energy & Mining
- Max Working Pressure(MPa):
-
3.17 MPa
- Video outgoing-inspection:
-
Provided
- Machinery Test Report:
-
Provided
- Marketing Type:
-
Hot Product 2019
- Warranty of core components:
-
1 Year
- Core Components:
-
Pressure vessel
- Capacity:
-
100-450L
- Place of Origin:
-
Zhejiang, China
- Brand Name:
-
Fanke
- Dimension(L*W*H):
-
83-356mm
- Weight:
-
70
- Warranty:
-
3 years
- Key Selling Points:
-
High Safety Level
- Showroom Location:
-
Egypt, United States, Mexico, Argentina, South Korea, Sri Lanka
- Nominal water capacity:
-
100-450L
- Certification:
-
ISO14001:2015/GB24159-2009/KGS
- Appearance:
-
silver colour Refined Polish
- serve:
-
Video technical support, Online support, Spare parts
- Static evaporation rate(%/d):
-
2.1%/d
- Application Medium:
-
LOX,LNG,LAr,LCO2,LN2O,LN2
- Nominal weight:
-
70~397kgs
- Material:
-
Mn,CrMo,CrMo4,ST52
- Outside Diameter:
-
83-356 mm
- MOQ:
-
1 Piece
Supply Ability
- Supply Ability
- 50000 Piece/Pieces per Year
Packaging & delivery
- Packaging Details
1.Export standard packaging.
2. Each packed with insulated cover.
3. one piece in one carton
4. If necessary, wooden case or pallet is available.
5. customer requirements
- Port
Ningbo port
- Picture Example:
-
- Lead time:
-
Quantity(pieces) 1 – 20 21 – 50 51 – 100 >100 Lead time (days) 10 20 30 To be negotiated
Online Customization
Customise Now
|
Product Specification
|
|||||||
|
Product Model
|
DPL-400
|
DPL-175
|
DPL-195
|
DPL-210
|
DPL-410
|
DPL-450
|
|
|
Diameter*Height(mm)
|
750*850*1900
|
508*1500
|
508*1620
|
508*1707
|
750*850*1770
|
750*850*1900
|
|
|
Working Pressure(Mpa)
|
2.88
|
1.4/2.01/2.88
|
1.4/2.01/2.88
|
1.4/2.01/2.88
|
1.4/3.17
|
1.4/3.17
|
|
|
Pressure Relief Valve(Mpa)
|
3.45
|
1.59/2.41/3.45
|
1.59/2.41/3.45
|
1.59/2.41/3.45
|
1.59/3.45
|
1.59/3.45
|
|
|
Inner Container Bursting Disc(Mpa)
|
5.17
|
2.60/3.62/5.17
|
2.60/3.62/5.17
|
2.60/3.62/5.17
|
2.60/5.70
|
2.60/5.7
|
|
|
Max.Liquid Capacity(L)
|
400
|
175
|
195
|
210
|
410
|
450
|
|
|
Usable Liquid Capacity(L）
|
380
|
166
|
185
|
197
|
389
|
427
|
|
|
Evaporation Rate(LN2)
|
≤1.8%
|
≤2.1%
|
≤2.1%
|
≤2.1%
|
≤1.8%
|
≤1.8%
|
|
|
Tare Weight(Kg)
|
308
|
110/125/145
|
117/133/158
|
122/139/165
|
290/—
|
290/397
|
|
|
Oxygen(Kg)
|
433
|
189
|
210
|
226
|
443
|
487
|
|
|
Nitrogen(Kg)
|
307
|
134
|
150
|
161
|
315
|
346
|
|
|
Argon(Kg)
|
532
|
208
|
259
|
278
|
548
|
602
|
|
|
Natural Gas(Kg)
|
—-
|
70
|
76
|
86
|
179
|
—–
|
|
|
CO2(Kg)
|
418
|
183
|
204
|
219
|
325
|
470
|
|
|
NO2(Kg)
|
468
|
191
|
213
|
227
|
448
|
492
|
|
